6.3.2 Type key
This type key is applicable to the configurator in Peerless
Product Center.
Example: 6AEF16G-1-UF-1/7-P-M-US-R
Code Example Designation
6 6 inches Outlet flange [inch]
AEF Horizontal split case fire pump Pump type
16 16 inches Maximum impeller diameter [inch]
[ ] Not relevant
Impeller design
G
....
....
1 125 lb, inlet; 125 lb, outlet
Inlet and outlet flange rating
2 125 lb, inlet; 250 lb, outlet
3 250 lb, inlet; 250 lb, outlet
4 125 lb, inlet; 400 lb, outlet
X Special
UF UL listed and FM approved
Approvals
UC UL Canada listed approved
UL UL listed approved
FM cFMus approved
1 Cast iron (ASTM 48 CL 35A or 40A)
Casing material
2 Ductile iron (ASTM A536 60-40-18)
3 316SS
4 316LSS
5 CD4MCu/A84
9 Nickel-aluminum-bronze (ASTM B148)
X Special
1 Cast iron (ASTM 48 CL 35A or 40A)
Impeller material
3 316SS
4 316LSS
5 CD4MCu/A84
7 Silicon brass or bronze (ASTM B584)
9 Nickel-aluminum-bronze (ASTM B148)
X Special
P Packing
Seal
S Split seal, single
C Cartridge seal, single
X Special
M Mounted on base with driver
Mounting options
B Bare-shaft pump
L Mounted on base without driver
BA Baldor
Driver manufacture
CL Clarke
16
