PEERLESS Smartmount ST670 Installation And Assembly

3 of 27
ISSUED: 11-7-07 SHEET #: 202-9244-1
CC
AA BB
DD
FF
EE
Adapter Bracket Fasteners
M4 x 25 mm (4)
504-1015
M4 x 12 mm (6)
504-9013
M5 x 12 mm (4)
520-1027
M5 x 25 mm (4)
520-9543
M6 x 12 mm (4)
520-1128
M6 x 25 mm (4)
520-1208
M8 x 16 mm (6)
520-9257
M8 x 40 mm (4)
520-1136
I.D. .34" (8.6 mm) (4)
540-1059
M6 x 20 mm (4)
520-9402
M6 x 30 mm (4)
510-9109
M8 x 25 mm (4)
520-1031
multi-washer (6)
580-1036
I.D. .22" (5.6 mm) (4)
540-1057
Parts may appear slightly different than illustrated.
I.D. .35" (8.9 mm) (6)
5W1-035-X01
M10 x 15 mm (4)
520-1305
NOTE: The sorted-for-you™ fastener pack included was made specifically for your product and may not contain all components shown below.
Description Qty. Black Silver Black Silver
XX AA
wall plate 1 200-1901 200-4901 200-1901 200-4901
XX
200-1902 200-4902 200-1902 200-4902
XX BB
1 201-1475 201-4475 201-1476 201-4476
XX
201-1479 201-4479 201-1480 201-4480
XX CC
1 201-1473 201-4473 201-1474 201-4474
XX
201-1477 201-4477 201-1478 201-4478
XXXXDD
6 5S1-015-C03 5S1-015-C03 5S1-015-C03 5S1-015-C03
XXXXEE
6 590-0097 590-0097 590-0097 590-0097
XXFF
1 not included not included 560-1146 560-1146
#14 x 2.5" wood screw
alligator
®
anchor
4 mm allen wrench
ST670P, ST670P-S ST680P, ST680P-S
left tilt bracket
right tilt bracket
ST670, ST670-S ST680, ST680-S
Before you begin, make sure all parts shown are included with your product.
Parts List Non-Security Security
