25
instructions provided with the base.
9• Ifthebaseisalreadyattachedinthevehicle,ensurethatits
Isofix attachments are extended to their maximum length.
10•Removetheprotectivebaseattachedtothecarseatwith
thespecialreleaseswitches(ArrowsAandB).
11•PositionthecarseatontheIsofixBase0+1andsecurethe
rear connectors of the car seat to the attachment points
ofthebasenearesttothevehicleseat(ArrowA).Pressthe
frontpartofthecarseatuntilitclicksintoplace(ArrowB).
12• IMPORTANT: The two signals behind the Isofix Base go
from red to green to indicate that the car seat is properly
attached to the base.
13•Pullthehandleonthebase(ArrowA)andpushthebase
with the car seat against the vehicle’s seat until they can go
nofurther(ArrowB).
IMPORTANT: It is possible to check that the Isofix base
is correctly positioned by looking at the signals on the
handle.OK(green)indicatesthatthepositioniscorrect,
NO(red)indicatesthattheprocedurehasbeencarriedout
incorrectly and must be repeated until the handle only
shows the term “OK”.
IMPORTANT: Once the procedure is complete, move
the base to check that both Isofix points are actually
attached.
Howtoputthechildinthe Viaggio1
Duo-Fix ASIPcarseat
14•Beforesittingthechildonthestroller,releasethesafety
harness by pushing the red button in the buckle of the leg
divider strap.
15•Liftthesafetyharnessandattachthebucklestotheelastics
in the sides.
16•Sitthechildinthestrollerandadjustthesafetystraps
round the child’s shoulders and waist, as shown in the
picture.
17•Fastentheharnessbyoverlappingthetwostrapsand
inserting the buckles into the leg divider strap until they
click into place.
18•Thechildissittingcorrectlywiththesafetyharness
fastened properly.
19•Totightenthestrap,pullthecentraladjustingstrap
towards you as shown in the picture. The straps will tighten
round the child. Be careful not to pull too much.
IMPORTANT:Donottightentoomuch(theharness
shouldbelooseenoughforyoutoslipafinger
betweenthestrapandthechild’schest).
20•Toloosenthesafetystraps,pushthebuttoninthemiddle
of the car seat and at the same time pull the straps towards
you.
IMPORTANT:Grabholdofthesafetyharnessunder
theshoulderpads,asshowninthepicture.
• Theseathasaboostercushionwhichissuitableforsmall
babies and when the safety harnesses are in the first level.
Whenthechildisolder,removetheboostercushion.
21•Toremovetheboostercushion,pullitoutofthesafety
harness and the sides of the car seat.
Howtoadjusttheheightoftheheadrest
The head rest must be adjusted to match the child’s height.
Thereare7positions.Toadjusttheheadrest:
22•liftthestripinthemiddleoftheheadrestandpullitup
towards the desired position. If you want to put the head
rest back into the lower position, lift and lower the strip
and adjust the head rest in the desired position.
23•Whenthestrapsarepositionedcorrectly,thechild’s
shoulders will be just below the point where the straps pass.
24• IMPORTANT: The straps must not be too high or too
low with respect to the child’s shoulders.
25•TheViaggio1 Duo-Fix ASIP car seat can be inclined in 4
different positions, both when it is attached to the base
and when it is attached to the Isofix Base 0+1. To incline
thecarseat,presstheleverunderneath(fig.a)andpullit
towardsyouintotherequiredposition(fig.b).
• To release the Viaggio1 Duo-Fix ASIP car seat from the Isofix
Base0+1,pressthesameleverinthesameway(SeePoint10).
Howtoremovethelining
ToremovetheliningoftheViaggio1Duo-FixASIPcarseat:
• sliptheboostercushionoffifthereisone(point21);
• unfastenthesafetyharness(point14);
26•unfastenthestrapsfromthebackattachmentpoint;
27•release,fromtheback,thesafetyharnessstrapsandpull
