9
Type Label:
General Symbols
1. Ensure proper disposal
2. CE-mark
Safety Symbols
3. Read documentation!
4. Warning: Dangerous voltage!
5. Warning: Hot Surfaces!
6. Wait for 5 Minutes before opening!
Bottom of Inverter:
7. DC connection area
8. Ethernet / RS485
9. Wi-antenna
10. Digital I/O connection
11. AC-plug
12. PE-connections
Periodic Inspection:
Check if all markings and safety
symbols are clearly visible on the
inverter. Replace if necessary.
Labels and Markings on the Inverter
Targhetta identicativa:
Simboli generali
1. Smaltire conformemente alle
disposizioni
2. Marchio CE
Simboli di sicurezza
3. Leggere le istruzioni di
installazione!
4. AVVERTENZA! Tensione
pericolosa!
5. Avvertenza! Superci calde!
6. Attendere 5 minuti prima di aprire!
Parte inferiore dell’inverter:
7. Area di collegamento DC
8. Ethernet / RS485
9. Antenna WLan
10. Ingressi e uscite digitali
11. Connettore AC
12. Collegamenti PE
Controllo periodico:
Vericare che tutti i contrassegni e i
simboli di sicurezza sull’inverter siano
ben leggibili. Sostituire i contrassegni
mancanti.
Indicazioni e simboli sull’inverter
