Peimar PSI-3400TLM User Manual

25
+
-
+
-
DC
-
DC+
2
1
11-04-03 1012:17
Standard
Today
Total
5 hours
14.6 kwh
52.7
kwh
5 hours
1 minutes
<> to Main MenuESC
15.21 kw
14.60 kw
Normal
49.99 Hz
3
E
SC
O
K
1. It is possible to connect the two
input ports in parallel.
2. Install diodes in order to prevent
reverse currents.
3. When the ports are connected
in parallel: Set the input mode of
the inverter from “Independent” to
“Parallel”.
Parallel Connection of PV-Ports
EN
1. Gli ingressi possono essere
collegati in parallelo.
2. Installare i diodi per prevenire
corrente inversa.
3. Quando gli ingressi sono collegati
in parallelo: impostare gli ingressi
da “Indipendente” a “In parallelo”.
Collegamento in parallelo degli ingressi
IT
