Figure A
Figure B
In Service
In Bypass
Bypass Valve Operations
Figure A shows the system "in service" which allows water to flow in
and out of the tank. In this position the system would be considered
ON.
Figure B shows the system "in bypass" which will direct water straight
to the home without going in and out of the tank. In this position the
system would be considered OFF.
