Pella 6000 - Storm Door Installation Procedure; Initial Frame Preparation and Alignment; Hinge Orientation and Mounting Frame Setup

Right Hinge
Orientation
viewed from outside
Le Hinge
Orientation
viewed from outside
LEFT HINGE
Watch for this color
throughout the manual
RIGHT HINGE
Watch for this color
throughout the manual
3
Center in Opening
S
I
D
E
V
I
E
W
Align
outer
edges
Remove
glass
and
screen
Remember
this is the
INTERIOR SIDE
of the door
Lift
Snap
Determine the side you want your door to hinge.
FIRST, center
header frame in
entryway
opening ...
... THEN,
align with face
of brickmold.
Predrill the
two holes.
Secure with
jamb screws.
START
Your Installation
1
2
Continued
on page 4
3
5
6
Turn door
over.
Remove
shipping
clips.
Remove glass
and screen.
4
“Jamb Screw Bag”
unpainted
#8 x 3/4” Pan Head
Qty.
2
Drill 3/32”
Pilot Holes
