Pella 6000 - Closer Installation and Preparation; Closer Base Preparation and Side Determination; Closer Base Mounting and Securing

Top
Closer
Location
(Right Hinge)
Bottom
Closer
Location
(Right Hinge)
Approx.
1-1/2”
Approx.
1-1/2”
Right
Hinge
Illustrated
Left Hinge
Illustration
Top
Closer
Location
Bottom
Closer
Location
R
e
m
o
v
e
Align Arrow
with Notch on
Mounting Frame
Rest Against
Back of
Mounting
Frame
MOUNTING
FRAME
Right Hinge
Illustrated
Align
Arrow
with
Notch on
Mounting
Frame
Rest Against Back of
Mounting Frame
Interior
Side
of the
Door
RIGHT HINGE Install Closers
on This Side.
LEFT HINGE Install Closers
on This Side.
25
26
24
Continued
from
Hardware
Instruction
27
8
Continued on Page 9
Hole Plugs
Break off of closer base
Qty.
2
23
Predrill holes (3/32” bit).
Secure with screws.
Align closer base arrow with
small notch on mounting frame
(install both top and boom).
Break off alignment tabs.
Determine which
side to install the
closers
[Right versus Le].
Remove the two hole plugs
from the closer bases.
Insert into the factory
drilled holes near the top
corners of the door.
“Closer Screw Bag”
Unpainted #10 x 1” Pan Head
Qty.
4 each
Drill 3/32”
Pilot Holes
