Pella 6000 - Door Frame Adjustments and Handle Installation; Top Mounting Frame and Spacer Removal; Handle Kit Installation

Remove the two
yellow clips.
Re-install the
screws.
Reinstall
Remove
and
Discard
Leave this
plate in
place
Right
Hinge
Illustrated
18
19
20
21
Continued from page 6
Position top
mounting frame.
Note: if you have
interference with
siding, remove the
break-off tab with a
pliers, then caulk along
the back surface, for
protection from rain.
7
Go to the separate
hardware instruction
sheet in the handle kit
Install
your
handle
set.
Hardware
Instruction
Sheet
Handle Kit
Close door.
Rest mounting frame
on door.
Predrill the two
hole locations.
Secure with screws.
Left Hinge
Illustration
Factory
Installed
Spacer
Rest
on
Door
Remove the two spacers.
Break-off Tab
(Remove if necessary)
Factory
Installed
Spacer
Remove and Discard
“Mounting Frame Screw Bag”
unpainted
#6 x 1” Pan Head
Qty.
2
Drill 3/32”
Pilot Holes
22
