Pelltech PV20a - Specification; Pellets

PV20a / PV30a pellet burner
page 10/ 41
DK9902A1 www.pelltech.eu
Specification 1.3
Pellets 1.4
Wood pellets or saw dust granules are concentrated and homogenized wood fuel made by pressing
dried and comminuted wooden waist like sawdust and cutter shavings. Also stem wood is used. During
pressing no extra materials are added, pellets are held together by a natural ingredient found in wood –
the lignin. Pellets are neutral, renewable fuel. Its burning doesn’t spoil CO
2
balance in the atmosphere.
Pellets have to be stored in a dry and ventilated room. Only premium wood pellets e.g. ENPlus-A1 can
be used in PV20a/30a burners. Table 2 provides an overview of the most important wood pellet
properties and threshold values.
Description
Unit
PV20
PV30
L total lenght
mm
540
570
L1 burner housing lenght
mm
230
230
L2 burning chamber lenght
mm
170
200
⌀D burning chanber diameter
mm
146
162
⌀D1 burning chamber neck diameter
mm
88.9
88.9
⌀D2 internal feeder inlet diameter
mm
60
60
H total height
mm
240
240
H1 burner housing height
mm
200
200
W total width
mm
220
230
W1 burner housing width
mm
205
205
Mass
kg
11.2
12.2
Burners nominal capacity
kW
20
30
Burners minimal capacity
kW
10
14
Emission class EN 15270
-
5
5
Noise level
dB
52
52
Working temperature
o
C
0 - 60
0 - 60
Mains supply voltage
VAC
220-240
220-240
El. power at ignition
W
570
570
El. power, average
W
25 - 40
30 - 40
El. power at standby
W
4
4
Figure 3 Main measurements
Table 1 Burners’ main measurements
