Pelltech PV20a - Annex 3 Table of Parameters

PV20a / PV30a pellet burner
page 38/ 41
DK9902A1 www.pelltech.eu
Table 14 Connectors X1 and X2
X1
DescriptDescription
X2
Description
1
Igniter
1
-
2
Igniter
2
-
3
N – Supply mains
3
Battery’s “+ “ terminal (red)
4
Flue gas fan
4
Battery’s “-” terminal (black)
5
L1 – Supply mains
5
Flame sensor
6
Transformer ‘s primary winding
6
Flame sensor
7
Fan
7
Feeder auger’s “-“ (black)
8
Transformer ‘s primary winding
8
Feeder auger’s „+“ (red)
9
Boiler thermostat
9
Transformer’s secondary winding
10
External auger
10
Transformer’s secondary winding
10 Annex 3 Table of parameters
Vers 3.88.9
PV20a/20b
PV30a/30b
PAR
PAR name
Description
Unit
Def
Min
Max
Def
Min
Max
PAR1
FAN @10(15)
Fan speed at 1.power level PV20(PV30)
rps
24
22
27
25
23
28
PAR2
FAN @12(18)
Fan speed at 2.power level PV20(PV30)
rps
27
25
30
28
26
31
PAR3
FAN @14(21)
Fan speed at 3.power level PV20(PV30)
rps
29
27
32
30
28
33
PAR4
FAN @16(24)
Fan speed at 4.power level PV20(PV30)
rps
31
29
34
33
31
36
PAR5
FAN @18(27)
Fan speed at 5.power level PV20(PV30)
rps
34
32
37
37
35
40
PAR6
FAN @20(30)
Fan speed at 6.power level PV20(PV30)
rps
38
36
41
42
40
44
PAR7
FAN START
Fan speed at TESTING
%
140
80
240
140
80
240
PAR8
FAN @IGNITING
Fan speed at IGNITING and PRE-BURN
rps
25
20
35
25
20
35
PAR9
FAN @END BURN
Fan speed at END BURN
rps
20
10
40
20
10
40
PAR10
FAN @HOLD
FLAME
Fan speed at HOLD FLAME
rps
10
7
14
10
7
14
PAR11
HOLD FLAME ON
If HOLD FLAME is set to ON in main menu then
this function starts at any case. If HOLD FLAME is
set to AUTO in main menu, then this function
starts if time set with this parameter is shorter
than 2 sequential WAITING times.
min
15
5
30
15
5
30
PAR12
HOLD FLAME OFF
Max time when burner holds flame. HOLD FLAME
function in main menu has to be set to AUTO or
ON.
min
60
30
90
60
30
90
PAR13
MIN POWER
Minimum power level up to what burner
decreases output power. Applies if POWER in
main menu is in AUTO status only
kW
12
10
20
18
15
30
PAR14
MAX POWER
Maximum power level up to what burner
increases output power. Applies if POWER in main
menu is set to AUTO only
kW
18
10
20
27
15
30
