PressureMAT User Guide
Revision 8
Page 12/48
Specifications
Multi-channel models PMAT-S:
H x W x D: 7.86” x 4.47” x 2.25” 4.70” x 4.70” x 2.25”
(19.96 x 11.35 x 5.72 cm) (11.94 x 11.94 x 5.72cm)
Approx: 1.43 lbs. (0.65 kgs) 0.86 lbs (0.39 kg)
Material: ABS Plastic
Panel/wall mount optional
Temperature: 0–55° C (32–132° F)
Humidity: 0–95% RH non-condensing, Shipping/Storage:
–20° to +85° C
(warm up to rated accuracy = 6 min.)
8 button keypad with LEXAN® overlay
8 line LCD backlit blue- psi as XX.X and bar as X.XX
HR Models: X.XXpsi and bar as X.XXX
2.5 mm Circular Power Jack (center post positive)
12-24 Volts DC
4 Watts (powered by supplied appropriate wall supply)
Configured for PendoTECH Single Use Pressure Sensors*
Connector on reusable cable: DB15
Excitation voltage: 4.096V +/- 0.22%
Flow Meter Input
(2P, 2F and 3Ponly)
Input to measure 5V square wave frequency/pulse
• Normally OPEN or CLOSED via wiring
• 28 Volt AC/DC Maximum
• 1 amp closure, 2 amps maximum current
• 20 mS max turn on/off time
•
4-20mA Range: -10 to 75 psi (-0.69 bar to 5.17 bar)
HR Models: -1 to 3 psi (0.069 bar to 0.207 bar)
Accuracy: 0.1% of full scale
Sourcing w/Maximum Load: 400 Ohms
Load Impedance: Zero Ohm minimum resistance
Analog Input (4-20 mA)
(2P, 2A, and 3A only)
Screw terminal connector
4-20mA Range +/- 0.01% of full scale; 100 Ohms
FCC Part 15 Class B verified
FCC Part 68 5TUUSA-23969-DT-E
* See Appendix B for important information on this product
LEXAN® is a registered trademark of General Electric Company
