PressureMAT User Guide
Revision 8
Page 4/48
1. Overview of PendoTECH PressureMAT
The PressureMAT is a monitor, alarm, and transmitter system designed for use with Single Use
Pressure Sensors from PendoTECH. It is comprised of the control system box with user interface and
the connectors on the back panel where input and output components can be interfaced. If equipped,
the alarm output function includes a dry contact relay output. The transmitter function delivers an
analog 4 – 20 milliamp output signal corresponding to the pressure reading on the display. There are
numerous applications in biopharmaceutical production processes where the system can be used.
The models are as follows:
Model Number
Number of
Inputs
Number of
Outputs
Outputs
PMAT2*
2
4
2 Relays / 2 Analogs or 4 Relays
PMAT2P
2 pressure/1
flow/1 analog
4
4 Analogs [may be re-configured]
PMAT3
3
4
3 Analogs / 1 Relay (for all sensors)
PMAT3P
3 pressure/1 flow
4
4 Analogs [may be re-configured]
PMAT4A
4
4
4 Analogs
PMAT4R
4
4
4 Relays
PMAT3A
3 pressure/
1 analog
4
4 Analogs [may be re-configured]
PMAT2A
2 pressure/
2 analog
4
4 Analogs [may be re-configured]
PMAT2F
2 pressure/
2 flow
4
4 Analogs [may be re-configured]
PMAT-S*
1
3
1 Relay /1 Analog / 1 remote tare
* Available in “High Resolution” model with HR suffix
System Components Supplied:
• PressureMAT Instrument
• Cable(s) for connection of pressure sensors to the control system
• Connectors for cable for each output
• 4 Screws for mounting
• Power supply
Options:
• PMAT-STND Benchtop Stand
• PMAT-GUI PressureMAT Data Acquisition Software (Appendix C)
• PDKTP-RS232U RS-232 cable for data output to a PC via USB
• PMAT-PANEL Panel mount kit (Appendix D)
• PMAT-WALL4 Wall mount stainless steel box
• PDKT-650-298CVR Pressure sensor cable dust cover / zero simulator for PressureMAT
• PressureMAT Carts – contact PendoTECH for details
1.1. PressureMAT Instrument
