PressureMAT User Guide
Revision 8
Page 25/48
3. Flow Meter Function in PressureMAT-PLUS (2P, 3P & 2F)
3.1. Display
The home screen displays flow on the 4
th
line as shown below (PMAT3P shown and bar units shown).
1 Pressure X.XX bar
2 Pressure X.XX bar
3 Pressure X.XX bar
4 PV Rate X.XX mL/m
3.2. Back Panel
The back panel of the unit is as shown below:
PMAT3P:
PMAT2P:
