Specifications
Period A, B Single
Range A, B:
3.3 ns - 1000 s
Resolution:
100 ps
■ Display:
Main Parameter:
Period
Aux. Parameters:
Vmax, Vmin, Vp-p
Ratio A/B, B/A, C/A, C/B
Range:
10
-9
to 10
11
(one-pass
measurem., values < 1
with reduced resolution)
Freq Range A,B:
100 Hz to 400 MHz
Freq Range C:
Full input C range
■ Display:
Main Parameter:
Ratio
Aux. Parameters:
Freq 1, Freq 2
Time Interval A to B, B to A, A
to A, B to B
Range (normal
calculation):
Range (smart
calculation):
Resolution
Single Shot:
Input Frequency:
Min. Pulse Width:
Smart Calculation:
0 ns to +10
6
s
-10
6
to +10
6
s
100 ps
Lp to 160 MHz
1.6 ns
Smart Time Int. w. 4 time
stamps (2 consecutive Trig A
plus 2 consecutive Trig B) to
determine sign (A before B or
A after B)
■ Display:
Main Parameter:
Time interval
Aux. Parameters:
None
Pulse Width A, B
Range:
2.5 ns - 10
6
s
Input Frequency:
Lp to 200 MHz
Modes:
Pos. pulse width or
neg. pulse width
■ Display:
Main Parameter:
Pulse width
Aux. Parameters:
Vmax,Vmin,Vp-p
Rise and Fall Time A, B
Range:
Input Frequency:
Trigger Levels:
Min. Pulse Width:
Modes:
Min. Amplitude
■ Display:
Main Parameter:
Aux. Parameters:
1.5 ns - 1000 s
Lp to 160 MHz
(square wave)
Default 10% and
90%
Manually adjustable
1.6 ns
Rise or fall time
100 mVp-p
Rise or fall time
Slew rate, V
max,
V
min
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
8-4
