Pendulum CNT-91 - Time Interval Error (TIE) A, B; Phase a Rel. B, B Rel. a; Duty Factor A, B

Specifications
Calibration
Mode:
Closed case, menu-con-
trolled.
Calibration Input:
A
Password
Protection:
ON or OFF
Input Frequen-
1.0, 1.544, 2.048, 5.0 or 10.0
cies used for TB
MHz
Calibration:
Definition of Terms
Calibration Ad-
The maximum tolerated
justment
Toler-
deviation from the true 10 MHz
ance:
frequency after calibration. If
the timebase frequency does
not exceed the tolerance limits
at the moment of calibration, an
adjustment is not necessary.
Total Uncertainty:
The total possible deviation
from the true 10 MHz
frequency under influence of
frequency drift due to aging
and ambient temperature
variations versus the reference
temperature. The operating
temperature range and the
calibration interval are part of
this specification.
See also timebase specifications on page 8-44.
General
Specifications
Environmental Data
Class:
MIL-PRF-28800F, Class 3
Operat. Temp:
0 °C to +50 (+45)* °C
Storage Temp:
-40 °C to +71 °C, non-condensing,
@ <12000 m
Humidity:
5-95 % @ 10-30 °C
5-75 % @ 30-40 °C
5-45 % @ 40-50 (45)* °C
4600 m
Max. Altitude:
Random and sinusoidal per
Vibration:
MIL-PRF-28800F, Class 3
Half-sine 30G per
Shock:
MIL-PRF-28800F; bench
handling
Transit Drop
Transport box tested according to
Test:
UN-D 1400 drop test program 1.
Heavy-duty transport case and
soft carrying case tested
according to
MIL-PRF-28800F.
*CNT-91R only
Reliability:
MTBF 30000 h, calculated
Safety:
Designed and tested for
Measurement Category I,
Pollution Degree 2, in ac-
cordance with EN/IEC
61010-1:20
01 and
CAN/CSA-C22.2 No.
61010-1-04 (incl. approval)
EMC:
EN 61326 (1997) A1 (1998),
increased test levels per EN
50082-2, Group 1, Class B, CE
8-42
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
