PENNBARRY
6
Wall Sleeves effectively add depth to the wall where the fan and several of its
accessories will be installed. This provides more fl exibility and convenience
to secure these parts, as well as protection and a neat appearance. Standard
construction is galvanized steel. Standard shipment is knocked down for BHM
and BHH, or optionally available as factory assembled. Shipment for other
models is factory assembled only. A guard is provided for either front or rear
installation.
Wall Sleeves
Breezex Accessories
Refer to appropriate drawings on pages 3, 4 and 5.
FAN AND WALL SHUTTER SHOWN
FOR REFERENCE ONLY
ANGLE
SUPPORT
(BY OTHERS)
A
SQ.
E
SQ.
C
MIN.
Wo
SQ.
D
*BCH only
*BHH only
SIZE
P SERIES BC/BLL/BCH
10 12 16 18 20 24 24 30 36 42* 48* 54* 60*
Wo
SQ.
15 3/4 17 3/4 23 1/2 25 27 1/2 33 28 3/4 34 3/4 40 3/4 46 3/4 55 61 67
A
SQ.
15 1/4 17 1/4 23 24 1/2 27 32 1/2 28 1/4 34 1/4 40 1/4 46 1/4 54 1/4 60 1/4 66 1/4
C
MIN.
444455666677 1/27 1/2
D
18 3/4 18 3/4 22 3/4 23 24 3/4 30 3/4 30 3/4 35 38 44 47 1/2 48 48
E
SQ.
17 5/8 19 5/8 25 3/8 26 7/8 29 3/8 34 7/8 30 5/8 36 5/8 42 5/8 48 5/8 56 5/8 62 5/8 68 5/8
SIZE
BHM/BHH
24 30 36 42 48 54* 60*
Wo
SQ.
32 3/4 38 3/4 44 3/4 50 3/4 57 63 69
A
SQ.
32 1/4 38 1/4 44 1/4 50 1/4 56 1/4 62 3/8 68 3/8
C
MIN.
6666777
D
36 39 41 41 41 48 48
E
SQ.
34 3/8 40 3/8 46 3/8 52 3/8 58 3/8 64 3/8 70 3/8
BREEZEX
MODEL
NUMBER
MOTOR OPERATED
SHUTTER
FRONT
GUARD
REAR GUARD WEATHERSHIELD
C
SQ.
E
SQ.
A
SQ.
C
SQ.
A
SQ.
BA
SQ.
BC
BX12Q
15 18 15 1/8 15 1/8 14 11/16 12 1/2 15 1/4 17 7/8 12 3/8
BX14Q
15 18 16 5/8 16 5/8 16 3/16 12 1/2 16 1/4 19 12 3/4
BX16Q
19 22 19 3/8 19 3/8 18 15/16 12 1/2 19 20 13 7/8
BX16T
BX18Q
21 24 21 3/8 21 3/8 21 15/16 12 1/2 21 22 3/8 14 1/2
BX18T
BX20Q
22 3/4 25 3/4 23 3/8 23 3/8 22 15/16 12 1/2 23 23 1/4 15 1/2
BX20T
BX24Q
26 3/4 29 3/4 27 3/8 27 3/8 26 15/16 13 1/2 27 26 1/8 17 1/4
BX24T
Options and Accessories
Breezeway
Dimensional Data
