HP TENSION PHASE
TYPE DE
MOTEUR
INTENSITÉ
DE CHARGE
MAXIMALE
VALEUR
NOMINALE
DU FUSIBLE
(INTENSITÉ)
DISTANCE EN PIEDS (MÈTRES) DU MOTEUR À LA SOURCE
D’ALIMENTATION
0 À 100 (0 À 30)
101À200
(31À61)
201À 300(62À91) 301 À 400 (92 À 122)
TAILLE DES FILS AWG (MM^2)
1/2 115/230 1 ODP 8,5/4,3 15/15 14/14 (2/2) 12/14 (3/2) 10/14 (5,5/2) 8/14 (8,4/2)
1/2 230/460 3 ODP 2,3/1,15 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1/2 115/230 1 TEFC 8,2/4,1 15/15 14/14 (2/2) 12/14 (3/2) 10/14 (5,5/2) 8/14 (8,4/2)
1/2 230/460 3 TEFC 2,2/1,1 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
3/4 115/230 1 ODP 11,4/5,7 20/15 14/14 (2/2) 10/14 (5,5/2) 8/14 (8,4/2) 6/12 (14/3)
3/4 230/460 3 ODP 3,1/1,55 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
3/4 115/230 1 TEFC 11,6/5,8 15/15 14/14 (2/2) 10/14 (5,5/2) 8/14 (8,4/2) 6/14 (14/2)
3/4 230/460 3 TEFC 2,9/1,45 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1 115/230 1 ODP 12,2/6,1 25/15 12/14 (3/2) 8/14 (8,4/2) 8/14 (8,4/2) 6/12 (14/3)
1 230/460 3 ODP 3,6/1,8 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1 115/230 1 TEFC 14,2/7,1 20/15 12/14 (3/2) 8/14 (8,4/2) 6/14 (14/2) 6/12 (14/3)
1 230/460 3 TEFC 3,6/1,8 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
11/2 115/230 1 ODP 18,4/9,2 30/20 10/14 (5,5/2) 8/14 (8,4/2) 6/12 (14/3) 4/10 (21/5,5)
11/2 230/460 3 ODP 4,7/2,35 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
11/2 115/230 1 TEFC 18,0/9,0 25/15 10/14 (5,5/2) 8/14 (8,4/2) 6/12 (14/3) 4/10 (21/5,5)
11/2 230/460 3 TEFC 4,8/2,4 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
2 115/230 1 ODP 22,8/11,4 45/25 10/14 (5,5/2) 6/12 (14/3) 6/12 (14/3) 4/10 (21/5,5)
2 230/460 3 ODP 6,8/3,4 15/15 14/14 (2/2) 14/14 (2/2) 12/14 (3/2) 12/14 (3/2)
2 230 1 TEFC 10,4 15 14 (2) 14 (2) 12 (3) 10 (5,5)
2 230/460 3 TEFC 6,0/3,0 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 12/14 (3/2)
21/2 115/230 1 ODP 22/11 45/25 10/14 (5,5/2) 8/12 (8,4/3) 6/12 (14/3) 4/10 (21/5,5)
21/2 230/460 3 ODP 8,5/4,25 15/15 14/14 (2/2) 14/14 (2/2) 12/14 (3/2) 10/14 (5,5/2)
21/2 230 1 TEFC 11,7 15 14 (2) 14 (2) 12 (3) 10 (5,5)
21/2 230/460 3 TEFC 7,0/3,5 15/15 14/14 (2/2) 14/14 (2/2) 12/14 (3/2) 12/14 (3/2)
TABLEAU II–DONNÉES RECOMMANDÉES EN MATIÈRE DE FUSIBLES ET DE CÂBLAGE–MOTEURS À 60CYCLES
