FLECK
®
9000/9100/9500 Service Manual • 9
Item No. QTY Part No. Description
1 ..............2 ...... 18728 ..............Nut, Tinnerman, U Type,
8-32
2 ..............1 ...... 11838 ..............Power Cord, 6' Fleck
....... 11839 ..............Power Cord, 12' Fleck
....... 40084-12 .........Power Cord, 12' U.S.,
Round, 120V Sys 5, 6, 7 &
2900/3150/3900 #4
....... 19885-01 .........Power Cord Assy,
Japanese
....... 11545-01 .........Power Cord Assy, 4' Black,
Euro w/Terminals
....... 14678 ..............Power Cord, U.S., 220/60
....... 19303-01 .........Power Cord Assy,
Australian w/Terminals
....... 40085-12 .........Power Cord, 12' US,
Round, 240V
....... 44149 ..............Transformer, 24V, 9.6VA
Residential Valves
....... 41475 ..............Transformer, 24V, 9.6VA,
European
3 ..............1 ...... 15202 ..............Harness, 9000/9500, Drive
....... 14822 ..............Harness, 2900
4 ..............1 ...... 15134 ..............Gear Assy, Drive, 1/2-inch
Stroke 9000/9500
5 ..............1 ...... 15135 ..............Gear, Drive, 9000
6 ..............1 ...... 14896 ..............Wheel, Geneva
7 ..............2 ...... 40422 ..............Nut, Wire, Tan
8 ..............2 ...... 19367 ..............Screw, Designer Cover,
Thumb 8-32 Blank UV
Stable Material
9 ..............1 ...... 15175 ..............Label, Shaft Position
10 ............2 ...... 14917 ..............Ring, Retaining
11 ............1 ...... 42296 ..............Plate, Ground, 9000/9500
12 ............1 ...... 14430 ..............Screw, Hex Washer St, 6 x
1/4 Type "B"
13 ............2 ...... 19160 ..............Screw, Phil Pan, Thread
6-32 x 3/8 Type 23 Zinc
14 ............1 ...... 18737 ..............Motor, 24V, 50/60 Hz,
1 RPM
....... 18738 ..............Motor, 120V, 50/60 Hz
1 RPM
....... 18739 ..............Motor, 220V, 50/60 Hz
1 RPM
15 ............1 ...... 15131 ..............Backplate, 9000,
Mechanical, SXT
....... 17784-05 .........Panel, Control, 9000/9500
XT
....... 17784-02 .........Panel, Control, 9000, 9500
w/Terminal Block
16 ............2 ...... 15172 ..............Screw, Flt Hd Mach,
4-40 x 1 3/8 Steel
Zinc Plate
17 ............2 ...... 10340 ..............Washer, Lock #4, Zinc
18 ............2 ...... 16433 ..............Switch, Miniature
19 ............1 ...... 10339 ..............Nut, Hex, 4-40 Zinc Plated
20 ............1 ...... 15331 ..............Screw, Hex Washer Mach,
10-24 x 3/4 410 S.S.
21 ............1 ...... 15133 ..............Gear Assy, Drive, 3/4-inch
Stroke
22 ............1 ...... 13547 ..............Strain Relief, Flat Cord Heyco
#30-1
1 ...... 13547-01 .........Strain Relief, Round Cord
23 ............1 ...... 15810 ..............Ring, Retaining
24 ............1 ...... 17331 ..............Cam, 9000, 9100, 9500
....... 17765 ..............Cam Assy, Aux Switch, 9000,
9100, 9500
25 ............1 ...... 15368 ..............Tube, Cable Guide, 2-Tank,
9000/9100
....... 17337 ..............Tube, Cable Guide, 9500
26 ............2 ...... 15372 ..............Washer, Thrust, 3/8
27 ............1 ...... 15425 ..............Meter Cable Assy, 13.25
inches 9000/9100 3/4-inch
STD & EXT
....... 15216 ..............Meter Cable Assy, 15.25
inches 9000/9100 1-inch STD
& EXT
....... 17744 ..............Meter Cable Assy, 20.75
inches 9500 1.5-inch STD &
EXT
28 2 ...... 15692 ..............Washer, Plain, 3/8-inch
30 ............1 ...... 10302 ..............Insulator, Limit Switch
31 ............2 ...... 15173 ..............Screw, Slot Rd Hd Mach, 5-20
x 3/8
32 ..................... * ......................Complete 9000/9100/9500
Powerhead Assy
Not Shown
1 ...... 60232-110 .......Cover, Designer, 1 Pc Black
1 ...... 60232-112 .......Cover, Designer, 1 Pc Black
w/Left Window, Electric
1 ...... 60320-10 .........Switch Assy, Drive Cam,
9000, 9100, 9500
*Call your distributor for Part Number
Item No. QTY Part No. Description
POWER HEAD ASSEMBLY CONTINUED
