Pentair FLECK9000 - 9000;9100;9500 (3200 Series) Electro Mechanical Timer Assembly

FLECK
®
9000/9100/9500 Service Manual • 7
Item No. QTY Part No. Description
1 ..............1 ...... 13870-03 .........Housing, Timer, 9000
2 ..............1 ...... 17870 ..............Label, Indicator, 9000 Timer
3 ..............1 ...... 15465 ..............Label, Caution
4 ..............1 ...... 16930 ..............Label, Instruction
5 ..............1 ...... 15227 ..............Plate, Clutch, Actuator
6 ..............1 ...... 10300 ..............Screw, Slot Hex Washer,
18-8 x 3/8
7 ..............1 ...... 17513 ..............Clip, Spring
8 ..............1 ...... 15407 ..............Washer, Plain, #4
9 ..............1 ...... 15228 ..............Spring, Return
10 ............1 ...... 16270-10 .........Program Wheel Assy,
9000/9100, 3/4-inch STD,
0-2, 100
....... 16270-30 .........Program Wheel Assy,
9000/9100, 1-inch STD,
0-5, 100
....... 16270-40 .........Program Wheel Assy,
9000/9100, 1-inch EXT,
0-25, 500
....... 16270-50 .........Program Wheel Assy,
9000/9100/9500, 3/4-inch
EXT, 1.5-inch STD,
0-10, 500
....... 16270-60 .........Program Wheel Assy, 9500,
1.5-inch EXT, 0-50, 000
10A ................... 24673 ..............Volume Label, Metric,
9000/9100, 3/4-inch STD,
0-8m
3
....... 24672 ..............Volume Label, Metric,
9000/9100, 1-inch STD,
0-20m
3
....... 24676 ..............Volume Label, Metric,
9000/9100, 1-inch EXT,
0-100m
3
....... 24675 ..............Volume Label, Metric,
9000/9100/9500, 3/4-inch
EXT, 1.5-inch STD 0-40m
3
....... 25027 ..............Volume Label, Metric, 9500,
1.5-inch EXT, 1.5-inch EXT
0-200m
3
11 ............1 ...... 13806 ..............Retainer, Program Wheel
12 ............1 ...... 13748 ..............Screw, Flt Hd St, 6-20 x 1/2
13 ............2 ...... 11999 ..............Label, Button
14 ............1 ...... 15223 ..............Actuator, Cycle
15 ............1 ...... 13886 ..............Know, 3200
16 ............4 ...... 13296 ..............Screw, Hex Washer,
6-20 x 1/2
17 ............1 ...... 17724 ..............Program Wheel, Pinion
Drive
18 ............1 ...... 17723 ..............Clutch, Drive Pinion
19 ............1 ...... 14276 ..............Spring, Meter Clutch
20 ............1 ...... 14253 ..............Retainer, Clutch Spring
21 ............3 ...... 14087 ..............Insulator
22 ............1 ...... 15314 ..............Switch, Micro, Modified
23 ............1 ...... 15320 ..............Switch, Micro, Timer
24 ............2 ...... 11413 ..............Screw, Pan Hd Mach,
4-40 x 1 1/8
25 ............1 ...... 13018 ..............Pinion, Idler
26 ............1 ...... 18563 ..............Spring, Idler Shaft
27 ............1 ...... 13017 ..............Gear, Idler
28 ............1 ...... 13164 ..............Gear, Drive
29 ............1 ...... 13887 ..............Plate, Motor Mounting
30 ............1 ...... 18743-1 ..........Motor, 120V, 60 Hz 1/30 RPM,
5600
....... 18824-1 ..........Motor, 230V, 50 Hz 1/30 RPM
....... 19170 ..............Motor, 120V 60 Hz 1/15 RPM
....... 18825 ..............Motor, 230V, 50 Hz 1/15 RPM
Mallory
31 ............2 ...... 13278 ..............Screw, Phil Hd Mach, 6-32 x
1/8 Steel Zinc
32 ............1 ...... 14265 ..............Clip, Spring
33 ............1 ...... 15055 ..............Timer, Main Drive Gear
34 ............1 ...... 19210-02 .........Program Wheel Assy, 9000
1/15
......................... 19210-05 .........Program Wheel Assy,
9000/3230
35 ...........23 ..... 15493 ..............Pin, Spring, 1/16 x 5/8 SS
36 ............1 ...... 15203 ..............Harness, 9000/9500, Timer
37 ............2 ...... 40422 ..............Nut, Wire, Tan
38 ............1 ...... 60320-02 .........Switch Kit, 3200/9000 Timer
Auxiliary
39 ..................... 61420-69 .........Program Wheel & Gear Assy,
5-30-5-10-2, 2 Min
Per Pin
....... 61420-80 .........Program Wheel & Gear Assy,
5-40-5-7-2, 2 Min Per Pin
40 ............1 ...... * ......................
Complete 9000 Meter
Immediate Timer Assembly
*Call your distributor for Part Number
Item No. QTY Part No. Description
9000/9100/9500 (3200 SERIES) ELECTRO
MECHANICAL TIMER ASSEMBLY
CONTINUED
