INTELLIFLO
®
2 VST Variable Speed Pump Installation and User’s Guide
Pump Menu: Speeds 1-8
SPEED 1-8
MENU
Pump Operating Modes
The IntelliFlo
®
2 VST Variable Speed Pump can be
programmed in three different modes:
Manual, Schedule, and Egg Timer. Speeds 1-4 can
be programmed in all three modes. Speeds 5-8 can
only be programmed in Schedule mode since there are
no buttons on the control panel for Speeds 5-8. The
default setting for Speeds 5-8 is “Disabled”.
Speed 1 (1-4)
Manual
Schedule
Egg Timer
Set Speed - D
Set Speed
Set Start Time
Set Stop Tim
e
Set Speed
Time
Speed 5 (5-8)
Schedule
Set Speed
Set Start Time
Set Stop Time
Disabled
Default: Disabled
Manual
Assigns a speed to one of the four Speed buttons
on the control panel. This mode can only be used for
speeds 1-4. Speeds 1 and 2 are Manual by default.
To operate in Manual mode, press one of the four
speed buttons and then press the Start/Stop button.
The pump will run the assigned speed for that speed
button.
Egg Timer
Speeds 1-4 can be programmed to run at a certain
speed and for a duration of time once a speed button
is pressed.
Speeds 3 and 4 are Egg Timers by default. If you
desire a different method of operation, speeds 3 and 4
can be changed to Manual mode in the control menu.
To operate in Egg Timer mode, press a speed button
and then press Start/Stop. The pump will run that
speed for the set amount of time and then turn off.
Schedule
Program speeds 1-8 start and stop at a specific time
during a 24 hour period. Speeds programmed in
Schedule mode will override any manually selected
speed once the next Schedule command commences.
Speed Menu Tree Options
Entering Password
1. Press any button (besides the speed button) to
prompt the screen for a password.
2. To enter password, use the Left and Right arrows to
move the cursor and the Up and Down arrow button
to scroll through the digit then press Save to confirm.
Setting Password
1. Check that the green power LED is on.
2. Press Menu. Press Select to select “Settings”.
3. Use the Up or Down arrow to scroll to “Device”.
4. Press Select.
5. Press Up or Down arrow to scroll to “Password”. The
default setting is “Disabled”.
6. Press Select.
7. Press Up or Down arrow to change the setting to
“Enabled”. Press Save to save.
8. Press the Down arrow. “Password Timeout” will be
displayed. The factory default time is 1 minute. This
means the IntelliFlo
®
2 VST Variable Speed Pump
will go into Password Protection mode 1 minute after
the last control panel key is pressed.
9. Press Select to change time setting from 1 minute
to 6 hours and press Save to save.
10. Press the Down arrow and then press Select on
“Enter Password” to change the setting.
11. Press the Left or Right arrows to move cursor and
press the Up or Down arrow to change the password
number to desired setting.
12. Press Save to save. To cancel any changes, press
Back to exit without saving.
MENU
SETTINGS
Pump Menu: Settings
