Item Eng. No Description Qty.
1 04625E001K CASE, GEAR 1
2 06201C000 GASKET, LID 1
3 19100A005 SCREW, CAP, 5/16"-18 UNC x 7/8", STEEL 8
4 04561B000 LID 1
5 17995A000 NIPPLE, SPECIAL VENT 1
05737A002 CAP, PIPE 1
6 7206-0094-00K DIPSTICK KIT WITH O-RING 1
7 110-000110-201 DIPSTICK 1
8 20164B020K SHAFT, PINION (INCLUDES SPACER) 1
20164B022A SPACER 1
05231A074 SHIM, GREEN, .003" THICK 4
05231A075 SHIM, PINK, .015" THICK 4
9 05674A013 CONE, BEARING 2
05675A009 CUP, BEARING 2
10 04563A001 CAP, OPEN 1
04741B000 CAP, CLOSED 1
05710A017 OIL SEAL 1
19101A013 SCREW, CAP, 3/8"-16 UNC x 1", STEEL 18
14946A003 WASHER, SEAL 18
11 20355C022K CRANKSHAFT 1
12 05674A021 CONE, BEARING 2
05675A013 CUP, BEARING 2
04624B004 CAP, BEARING 2
05068A016
SHIM, PLASTIC, PINK,
6-7/32" x 5-1/32" x .015"
6
05068A018
SHIM, PLASTIC, GREEN,
6-7/32" x 5-1/32" x .003"
6
05876A098 O-RING, 5" I.D., 5-1/8" O.D., 1/16" THICK 2
13 06211B041 CROSSHEAD AND PISTON ROD 3
14 17042C002 LINK, DUCTILE IRON 3
15 B01619A000 BUSHING 3
16 06171A010K SCREW, CAP 6
05454A004 LOCK WASHER 6
17 15245A101 BEARING, TWO HALVES 3
18 M01525A001 WRIST PIN 3
19 24959A001 HOUSING, OIL SEAL 3
22835A004 OIL SEAL 6
20 24958A000 RETAINER, OIL SEAL HOUSING 3
06106A034 SCREW, ALLEN 6
05059A434 GASKET, SEAL HOUSING 3
24648A000 KIT FOR REF. NO. 19 & 20 1
21 M01643A000 SPRING 3
22 05059A058 GASKET 3
23 17481A002 PLUG, PIPE, MAGNETIC 1
24 06106A038 SCREW, CAP, 3/4"-10 UNC x 2-1/2", STEEL 4
05454A003 LOCK WASHER 4
18639F002 FLUID END, COMPLETE (DUCTILE IRON) 1
20160F233
FLUID END, COMPLETE
(ALUMINUM BRONZE)
1
Item Eng. No Description Qty.
25 19105A008 SCREW, CAP, 5/8"-11 UNC x 2", STEEL 4
26 16654A006 SCREW, CAP, .551"-14 METRIC x 2-3/4" 3
27 18923A002 FOLLOWER 3
28 M01520A001 COVER-LOWER, BODY, CYLINDER 1
29 18922A000 PACKING, V-RINGS 3
30 18924A012 STUD, 2-9/16" x 2-1/16" x 1-1/2",
SST, PISTON
3
31 18879A002 RETAINER 3
32 05030A128 WASHER 3
33 18920A000 SPRING 3
34 18921A000 RING 3
35 18639F002 BODY, CYLINDER 1
18639F004 BODY, CYLINDER FOR AB PUMP 1
36 19109A046 NUT, HEX, 5/8"-11 UNC, STEEL 6
37 19109A072 NUT, HEX, 7/8"-14 UNF, STEEL 6
38 05659A560 STUD, 5/8"-11 UNC x 3-5/16" 6
39 05659A089 STUD, 7/8"-14 UNF X 4-1/2" 6
40 20848A000 CLAMP, VALVE CAP 3
41 20856A000 CLAMP, CYLINDER CAP 3
42 17390A000 CAP, VALVE 3
17390A002 CAP, VALVE FOR AB PUMP 3
43 05876A064 0-RING, 2-3/8" x 2-9/16" x 3/32" 3
44 20849A000 CAP, CYLINDER 3
20849A001 CAP, CYLINDER FOR AVAB PUMP 3
45 05876A096 O-RING, 3-1/4" x 3-1/2" x 1/8" 3
46 18925A013K SUCTION VALVE AND SEAT COMPLETE 3
47 18925A014K DISCHARGE VALVE AND SEAT COMPLETE 3
18835A004 SEAT, VALVE 6
18834A001 VALVE 6
18463A000 SPRING, VALVE, SUCTION 3
11829A000 SPRING, VALVE, DISCHARGE 3
18833A001 RETAINER 6
18832A001 SCREW, CAP 5/16"-24 UNF, SHOULDERED 6
48 20851A001 LINER, CYLINDER 3
05876A095
O-RING, 2-3/4" x 2-15/16" x 3/32"
FOR LINER
3
05022A065 PLUG, 1-1/4" PIPE 1
03210A010 PLUG, 3" PIPE 2
49 148850001 SCREW, MACHINE, 1/4"-20 UNC x 1/2" 2
05030A020 WASHER 2
50 05022A063 PLUG, 1/2" PIPE 3
51 05022A064 PLUG, 1" PIPE 3
