15
– 18 Range
REPAIR PARTS LIST (continued)
MODEL
R
EF
No.
DESCRIPTION
1 CASING & STUD ASSY. 800283 1PC 800283 1PC 800283 1PC 800283 1PC 800283 1PC
2 STUD (PK/10) 800113 1PC 800113 1PC 800113 1PC 800113 1PC 800113 1PC
NS ADAPTOR 504280 1PC 504280 1PC - 1PC - 1PC - 1PC
NS ORING CASING SPIGOT 702231 1PC 702231 1PC - 1PC - 1PC - 1PC
3B ORING ADAPTOR SPIGOT 702203 1PC 702203 1PC - 1PC - 1PC - 1PC
3C ORING DIFFUSER - 1PC - 1PC 702192 1PC 702192 1PC 702192 1PC
4 DIFFUSER 301431K 1PC 301481K 1PC 301884 1PC 301884 1PC 301941 1PC
5 SHAFT SLEEVE KIT 800895K 1PC 800895K 1PC 801007K 1PC 1PC 801007K 1PC
6 YOKE 301650GN 1PC 301650GN 1PC 301650GN 1PC 302010GN 1PC 301650GN 1PC
7 BOLT & BOLT SEAL (PK/12) 800242K 1PC 800242K 1PC 800242K 1PC 800242K 1PC 800242K 1PC
8 ORING CASING 700207K 1PC 700207K 1PC 700207K 1PC 700207K 1PC 700207K 1PC
9 BAFFLE 401322 1PC 401323 1PC - 1PC - 1PC 401322 1PC
10 SEAL KIT (INC. SEAL + ITEM 5) 800890K 1PC 800890K 1PC 800890K 1PC 800871K 1PC 800890K 1PC
11 IMPELLER - 1PH 506353K 1PC 503843K 1PC 403976K 1PC - 1PC 504413 1PC
IMPELLER - 3PH 506353K 1PC 503849K 1PC 403979K 1PC 404036 1PC 504413 1PC
12 NUT (PK/12) 800093K 1PC 800093K 1PC 800093K 1PC 800093K 1PC 800093K 1PC
13 PRIMING PLUG & ORING 800017K 1PC 800017K 1PC 800017K 1PC 800017K 1PC 800017K 1PC
NS PLUG 700230 1PC 700230 1PC 700230 1PC 700230 1PC 700230 1PC
14 MOTOR - 1PH 800445 1PC 800446 1PC 801350 1PC - 1PC 800446 1PC
MOTOR - 3PH 800448 1PC 800449 1PC 800450 1PC 800451 1PC 800449 1PC
15 BASE 504290GN 1PC 504290GN 1PC 504290GN 1PC 504290GN 1PC 504290GN 1PC
16 IMPELLER NUT (3PH) 603250 1PC 603250 1PC 603250 1PC 603250 1PC 603250 1PC
NS WASHER (PK/20) 800151 1PC 800151 1PC 800151 1PC - 1PC 800151 1PC
318430
P
ART NUMBER
182
318200
318230
P
ART. NO PART. NO PART. NO PART. N
185
-
318530
1
87
318700
318730
1
83
318300
318330
P
ART. NO
184
318400
