Pentair POOLSHARK - Replacement Parts List

14
PoolShark
®
Installation and User’s Guide
Replacement Parts List for the PoolShark
®
Model
Key Part Model Model
No. Description Qty. GW7500 GW7700
• Steering Kit (Incl. Key Nos. 2, 3, 4) 1 GW7505 GW7515
2 Swivel Housing 1
3 Swivel 1
4 Swivel Sprocket 1
23 Clutch Clip 1
• Clutch Kit (Incl. Key Nos. 5, 8, 21, 23) GW7503 GW7503
5 Oscillator Sleeve Bushing 1
8 Oscillator Sleeve 1
21 Clutch Assembly 1
• Gear Kit (Incl. Key Nos. 6, 10, 11, 17, 19, 20) GW7504 GW7504
6 Large Steering Drive Assembly 1
10 Shaft Plug 2
11 Long Sprocket Clip 1
17 Drive Shaft Assembly 1
19 Center Sprocket 1
20 Short Sprocket Clip 1
• Oscillator Kit (Incl. Key Nos. 12, 13, 14) 1 GW7502 GW7502
12 Small Sliding Seal 2
13 Oscillator 1
14 Large Sliding Seal 2
• Seal Flap Kit (Incl. Key Nos. 15, 16) 1 GW7506 GW7506
15 Right Seal Flap 1
16 Left Seal Flap 1
18 Chassis with Pad 1 41201-0242 41201-0242C
• Bumper Kit (Incl. Key Nos. 24, 25, 26, 27, 28) 1 GW7501 GW7511
24 Right Bumper Clip 1
25 Right Bumper Boot 1
26 Bumper 1
27 Left Bumper Boot 1
28 Left Bumper Boot Cli p 1
• Accessory Kit - Includes: 1 77705-0400 77705-0400
Regulator
1
Regulator Cap 1
Hose Weight 2
Flow Gauge 1
Reducer Cone 1
Eyeball Diverter 2
Vac Port Fitting 1
• Short Leader Hose 1 GW9540 GW9540
• Suction Hose, 1 meter segment 10 41201-0252 41201-0252
1 Outer Housing 1
7 Support Brace 1
9 Stainless Steel Axle 1
Parts Not Available Separately:
