Pentair POOLSHARK - Pool Preparation and Cleaner Assembly

3
PoolShark
®
Installation and User’s Guide
Pool Cleaner
Guage
Hose Wei
g
ht
s
E
y
ebal
l
R
educer
C
on
e
Vac Port Fitting
Regulator
Cap
Regulator
The following general information describes how to set-up your PoolShark
®
automatic pool cleaner.
NOTE: Before setting up this product, read and follow all warning notices and instructions starting
on page ii.
Preparation of your pool
Before you assemble and install your PoolShark
®
automatic pool cleaner, you should make sure that your
pool is clean and free of algae. If necessary, make the following preparations before proceeding:
•
Chemically balance the pool water
• Brush the pool and let the debris settle
• Hand vacuum the pool thoroughly
• Backwash and clean the filter and clean the pump
strainer basket, (see Figure 1)
• Start the pump
Cleaner Assembly
Check Parts
Remove the PoolShark
®
and all of its parts from the box
and check to make sure that all components were
included, (see Figure 2).
■ Pool Cleaner
■ Short Leader Hose
(1 Length, 0.36 Meter)
■ Hose (10 Lengths, 1 Meter Each)
■ Hose Weights (2)
■ Eyeball diverters (2)
■ Reducer Cone
■ Vac Port Fitting
■ Regulator
■ Regulator Cap
■ Flow Gauge
Skimmer
Basket
Pump
Strainer
Figure 2.
Figure 1.
