A. Wiring Diagrams
Anschlussdiagramm
Schémas électriques
L
N
1
Max.
C 25 A
30 mA
5LL8NN
W1 W2
RR
RAYSTAT-CONTROL-10
ABC
alarm*
2A max.
Heating cable
Heizband
Ruban chauffant
Temp� Pt 100 sensor
Temp� Sensor Pt 100
Sonde de température
* Optional
* Optional
* Option
R: Same colour
R: die gleiche Farbe
R: la même couleur
