Pentax EB-1970TK - Quick Reference of Injection Volumes for Internal Channel

– 11 –
General
1
1-1-4. Quick Reference of Injection Volumes for Internal Channel
The following table is designed to to help users better understand the injection volumes for
internal channel of video bronchoscopes.
Video
Bronchoscopes
Internal
Channel
Maximum
Volume
Capacity (mL)
Cleaning
Injection Volumes (mL)
Detergent
Rinse
Water
Air
EB-1170K
Suction
Channel
4 mL
①
:25 mL
②
:25 mL
①
:35 mL
②
:35 mL
①
:35 mL
②
:35 mL
EB-1570K 6 mL
EB-1970K 8 mL
EB-1970TK 9 mL
EB-1575K 6 mL
EB-1975K 8 mL
EB-1990i 4 mL
①
Injecting from suction nipple
②
Injecting from inlet seal (OF-B190)
Cleaning Process
Video
Bronchoscopes
Internal
Channel
Maximum
Volume
Capacity (mL)
High Level Disinfection
Injection Volumes (mL)
Alcohol Rinse
Injection Volumes (mL)
Disinfectant
Sterile
Rinse
Water
Air Alcohol Air
EB-1170K
Suction
Channel
4 mL
①
:25 mL
②
:25 mL
①
:35 mL
②
:35 mL
①
:35 mL
②
:35 mL
①
:15 mL
②
:15 mL
①
:35 mL
②
:35 mL
EB-1570K 6 mL
EB-1970K 8 mL
EB-1970TK 9 mL
EB 1575K 6 mL
EB-1975K 8 mL
EB-1990i 4 mL
①
Injecting from suction nipple
②
Injecting from inlet seal (OF-B190)
High Level Disinfection Process
