– 24 –
3) Check to conrm that detergent solution ows out from the suction channel opening
on the distal end of the endoscope.
4) Insert a syringe lled with detergent solution to inlet seal (OF-B190), and inject 25
mL of detergent solution into the suction channel.
(1)
(1) OF-B190
Figure 1.17
5) Detach the inlet seal cleaning adapter inlet seal (OF-B190), and cleaning adapter
(OF-B155) from the endoscope, and leave them to soak along with the endoscope in
detergent solution. Open the cap of inlet seal (OF-B190).
(1)
(2)
(1) OF-B190
(2) OF-B155
Figure 1.18
Endoscope
Cleaning
1
