– 37 –
1-2-5-1-2. Preparation
WARNING
Consult the manufacturer of the sterilization tray regarding its directions for
use.
CAUTION
Prior to the sterilization using STERRAD
®
NX™ system, ensure that Ventilation
cap (OF-C5) is attached to the scope. Failure to do so can result in bursting of
the bending rubber.
1) Detach cleaning adapter (OF-B155) and the inlet seal (OF-B190) are detached from
the scope.
(2)
(1)
(1) OF-B155
(2) OF-B190
Figure 1.28
2) Detach PVE soaking cap (OE-C9) from the scope.
3) Attach ventilation cap (OF-C5) to the scope
(2)
(1)
(1) OF-C5
(2) OE-C9
Figure 1.29
4) Lay the APTIMAX Instrument Tray Mat on APTIMAX Instrument Tray
5) Place the scope onto the mat as shown below
Figure 1.30
6) Cover the tray with the lid.
Endoscope
Sterilization
1
To Next Page
