Pentax EB-1970TK User Manual

– 41 –
4) Open the cap of inlet seal (OF-B190) during cleaning.
Figure 1.31
Cleaning of all external surfaces
5) Wash all surfaces of components and accessories three times with a lint-free gauze.
Cleaning of brushes
6) Wash the brush heads of cleaning brushes (CS6002SN, CS6015ST, CS3010S, CS-
C3S) by rubbing them with gloved ngers for 30 seconds.
Manipulating of valve mechanisms
7) While fully immersed, manipulate the suction control valve (OF-B179) mechanism
four times.
Figure 1.32
Filling of lumens with detergent solution
8) Using a syringe lled with detergent solution, inject 4 mL of the detergent solution
directly into the lumen of the suction control valve (OF-B179).
Figure 1.33
Soaking in detergent solution
9) While fully immersed, ensure there are no air bubbles on the surfaces of components
and accessories. If any bubbles are detected, ush them away with detergent solution
using a syringe.
10) Soak components and accessories in detergent solution according to the instructions
(temperature, concentration, time) specified by the detergent manufacturer. In the
case of Endozime, the immersion time is at 3 minutes
11) Remove the components and accessories from the detergent solution.
Accessory
Cleaning
1
