Pentax K-r Service Manual

77420 - 100/107 -
Table of Error Code 1 (SR unit adjustment)
SR unit adjustment, Table of Error Code (7– bb)
Error Code 
 (bb)
Contents
1
X MOVE ERROR
Lead wire is touching, connector contact NG, SR block NG
2
Y MOVE ERROR
〃
3 X DIR ERROR
〃
4 YL DIR ERROR
〃
Coil
5 YR DIR ERROR
〃
6 VREF ERROR connector contact NG Holl_Gain
7 IREF ERROR Lead wire is touching, Screw is stick on
8
RANGE OVER ERROR
〃
9 Ereki Limit ERROR
〃
Move_Range
10 Center Over ERROR
〃
11 Obit Core ERROR Weak connector contact, Bending flexible board
12 Obit Center ERROR
〃
Corner_Obit
13 Obit Corner ERROR
〃
15 "4HZ ERROR"
〃
16 "6HZ ERROR"
〃
Frequency
17 "10HZ ERROR"
〃
Gyro
14
GYRO VALUE
ERROR
Miss arranging gyro board lead wire
22 Reverse ERROR Coil is reversed
7












23 "0HZ ERROR" No use
Table of Error Code2 (SR unit adjustment)
SR gain adjustment, Table of Error Code (7 – bb)
Error Code 

(bb)

 
Contents
18 GYROWAVEERROR 
Gyro NG or condition of stage
Gyro
19 CHARTNOTCENTERERROR

Chart is not center of viewfinder
20 SRXERR 
Captured image is not right exposure
7
Caputure
21 SRYERR 〃

Pentax K-r Specifications

General

Megapixel	12.4 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPG
Maximum image resolution	4288 x 2848 pixels
Still image resolution(s)	1728 x 1152, 3072 x 2048, 3936 x 2624, 4288 x 2416
Optical zoom	- x
Focal length range	- mm
Interface	AV
Power source type	AC, Battery
Aperture range (F-F)	-
Camera shutter speed	1/6000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Centre weighted Auto Focus, Continuous Auto Focus, Multi Point Auto Focus, Selective Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic
Flash modes	Auto, Flash off, Manual, Pre-flash, Red-eye reduction, Slow synchronization
Flash guide number	16 m
Scene modes	Beach, Candlelight, Children, Close-up (macro), Fireworks, Museum, Night landscape, Night portrait, Portrait, Self-portrait, Snow, Sunset, Landscape (scenery)
Image editing	Crop, Rotating, Trimming
White balance	Auto, Cloudy, Daylight, Fluorescent, Manual, Shade, Tungsten
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Video resolutions	640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	25 fps
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC
Field of view	96 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.85 x
PictBridge	No
USB version	2.0
Product color	Black
Battery type	D-LI109, AA
Battery life (CIPA standard)	470 shots

Weight and Dimensions

Depth	68 mm
Width	125 mm
Height	97 mm
Weight	544 g
