Pentax K-r - Information of Jigs, Tools and Testers; Method for Making Temporally Bottom Cover

77420 - 105/107 -
Information of Jigs, Tools and Testers for 77420
Order No. 
* Exclusive use for 77420
Program soft for 77420 (For SLR/digital/SR)      No.95901-P419
DC coupler D-DC109 (Battery level adjustment/ Battery consumption check) Provide locally
*When adjusting battery level, affix insulation tape on Battery adaptor.
AC adaptor kit (D-AC50, DC coupler D-DC109, AC code) Provide locally
2 SD card (32MB or above)
(For FW, test shooting --- Recommend 512MB or above)
Temporary bottom cover (For M100 adjustment, Hand made)
--- Refer to the Method for making temporally bottom cover below.
*For 77170
77170 O100 cable (connect with 76700 O100 positioning jig)   No.95901-J146
*For 76830
K10D Master body for calibration
PENTAX will rend the master body. Please contact with us.
F5.6 Set plate for D20 (95901 D20)
--- *If you have D20-01, you do not need set plate.
F5.6 Set plate A (For Lens ID No.101~130) No. 95901-D27-00A
F5.6 Set plate B (For Lens ID No.1~99) No. 95901-D27-00B
DC code (connect with power supply or DC adaptor, Battery consumption check) No.95901-D25
*For 76700
76700 SR adjusting Jig (required AC100V) No.95901-J140
[Caution] If your area is not 100V, you must provide transformer at locally.
76700 SR unit adjusting base No.95901-J141
SR gain chart (Attached this service manual. The same as K100D)
*Others --- Common with 76700(K100D)
(Refer to service manual for 76700)
Method for making temporally bottom cover
[Required equipment] A401 bottom cover
① Cut off [ ] part of bottom cover
as shown in figure.
20
7
φ10
9
DC coupler
and DC code
