Pentax K-r Service Manual

77420 - 97/107 -
TECHNICAL INFORMATION
Battery consumption current
Condition : Lens [FA lens, A position], each mode and setting is default setting.
Lens---- ○ : With × : Without SD card---- ○ : With × : Without
  *Value on Battery equivalent --- DC adaptor + Power supply (3A or above)
   *Value on AC power supply --- DC adaptor + AC adaptor
*5,6 and 7 are peak value averages. Other value is average.
Battery equivalent
Condition of camera
Lens Card
DC6.0V DC8.3V
ACPower
supply
DC8.3V
○ × 200μA
200μA
200μA
Main SW/OFF*
○ ○ 200μA
200μA
200μA
1
× × 200μA
200μA
200μA
○ × 300μA
300μA
300μA
2
After auto power OFF
× × 300μA
300μA
300μA
Main SW/ON (Meter OFF) ○ ×
400mA
350mA
350mA
○ ○
400mA
350mA
350mA
3
× ×
400mA
350mA
350mA
Main SW/ON (Meter ON) ○ ×
540mA
500mA
500mA
4
○ ○
540mA
500mA
500mA
5
Charging Flash (Meter ON) * ○ ×
2,200mA
2,500mA
2,500mA
○ ×
2,800mA
2,800mA
2,800mA
6
Driving AF motor *
(phase difference AF)
SDM
×
1,500mA
1,200mA
1,200mA
○ ×
2,800mA
2,800mA
2,800mA
7
Driving AF motor *(Contrast AF)
SDM
×
1,800mA
1,600mA
1,600mA
Releasing shutter * ○ ×
3,600mA
3,600mA
3,600mA
8
○ ○
3,600mA
3,600mA
3,600mA
9
Recording image after release the shutter
○ ○
600mA
600mA
600mA
10
Bulb ○ ○
1,000mA
1,000mA
1,000mA
11
Displaying menu (LCD) ○ ×
600mA
600mA
600mA
12
Displaying menu (Video output) ○ ×
600mA
600mA
600mA
13
Displaying playback image ○ ○
600mA
600mA
600mA
14
Recording playback image in the card ○ ○
600mA
600mA
600mA
15
Stand by for USB communication ○ ○
500mA
500mA
500mA
16
Reading playback image in the card
with USB communication
○ ○
500mA
500mA
500mA
17
During Live view ○ ○
1,100mA
1,000mA
1,000mA
18
Stand by for Movie ○ ×
1,100mA
1,000mA
1,000mA
19
Recoding Movie ○ ○
1,200mA
1,100mA
1,100mA
20
Playback Movie ○ ○
600mA
600mA
600mA
*:Replacing T100 (back up capacitor is not charged)
