Pentax K-r Service Manual

77420 - 96/107 -

2-2. Method for Updating Firmware version for Service
The same as “2. [Adjustment] Initialization when replace T100” --- “2-1. Writing FW”
[Required equipment] SD card for product Firmware, AC adaptor, or full capacity of battery.
[Caution]When executing this updating, the camera will be initialized.
[Caution] Use AC adaptor, or full capacity of battery.
①Turn OFF the camera.
②Insert the SD card for product FW into the camera.
The SD card cover must open during updating.
③Turn the main switch to ON while opening SD card cover.
④Right screen is displayed on LCD monitor
*If you cancel the update, disconnect the power first then
remove SD card.
⑤Remove the SD card when the message [>>> EJECT SD CARD <<<] is
displayed then starting updating. (It takes approx 90sec for loading firmware)
[CAUTION]Do not turn OFF the camera.
⑥When [POWER OFF] is displayed, Turn OFF the camera.
Updating is completed automatically.
DETECTEDBOTHF/WFILE
NOWLOADING
DETECTEDFIRMWAREFILE
COMPLETELOADING
‑‑‑‑‑‑‑CPU‑‑‑‑‑‑‑‑
CURRENTVER.1.00.00.01
UPDATEVER.1.00.00.01
=======DSP========
CURRENTVER.1.00.00.01
UPDATEVER.1.00.00.01
>>>EJECTSDCARD<<<
PENTAXK‑r
UPDATINGDSPFIRMWARE 
SECTOR**>>PROGRAM

NEVERPOWEROFF
PENTAXK‑r
UPDATINGDSPFIRMWARE

****COMPLETE****
VERSION1.00.00.01

POWEROFF 
