Pentax K20D Quick Guide

11
Attaching the Lens
It is recommended to use the DA, D FA, FA J or other lenses with an
Aperture s (Auto) position.
1 Check that the camera is turned off.
2 Remove the body mount cover
(1) and lens mount cover (2).
Be sure to put the lens down with the
lens mount side facing upward to
protect the lens mount from damage
after removal.
3 Align the Lens mount index
(red dots) on the camera and
the lens, and secure by turning
the lens clockwise until it
clicks.
After attaching, turn the lens
counterclockwise to check that the lens
is locked in place.
• Turn the camera off before attaching or removing the lens to prevent
unexpected lens movement.
• We assume no responsibility nor liability for accidents, damages and
malfunctions resulting from the use of lenses made by other manufacturers.
For further information and precautions on selecting the lens or attaching or
removing the lens, refer to the Operating Manual (p.50 - 51 and 249 - 251).

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
