Pentax K20D - Inserting the Battery

8
Inserting the Battery
1 Open the battery cover.
Lift the battery cover unlock lever, turn
towards OPEN (1) to unlock, and then
pull the cover open (2).
2 Face the S mark on the
battery towards the
monitor, push the
battery lock lever in the
direction of the arrow
(1) and insert the
battery.
Insert until the battery locks.
To remove the battery, push
the battery lock lever in the direction of the arrow (1) with your hand.
The battery pops out slightly. Remove it.
3 Close the battery cover (1)
and turn the battery cover
unlock lever towards CLOSE
(2) to lock.
Stow the battery cover unlock lever
when finished closing.
For further information and precautions for the battery, refer to the Operating
Manual (p.2 - 3 and p.35 - 39).
2
1
1
Battery lock lever
2
1
