Pentax K20D Quick Guide

19
Adjusting the Viewfinder Diopter
Adjust the viewfinder to suit your eyesight.
If it is difficult to see the viewfinder image clearly, slide the diopter
adjustment lever sideways.
You can adjust the diopter from approximately –2.5m
-1
to +1.5m
-1
.
1 Look through the viewfinder
and point the camera at a white
wall or other bright and
consistent surface. Slide the
diopter adjustment lever left or
right.
Adjust the lever until the AF frame in
the viewfinder is focused.
The FP Eyecup is attached to the viewfinder
portion when camera leaves the factory.
Diopter adjustment is available with the F
P
Eyecup attached. However, adjustment is
easier with the eyecup removed. To remove
the F
P Eyecup, press in one side and pull it
out in the direction of the arrow.
To attach the F
P Eyecup, align it with the
groove on the viewfinder eyepiece and push
it into position.
AF frame

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
