23
1
Getting Started
Use of the AC adapter kit K-AC51 (optional) with a household power
supply is recommended if you intend to use the camera for a long time
or connect it to a computer.
(The AC adapter kit K-AC51 includes AC adapter D-AC5, DC coupler
D-DC51, and AC plug cord D-CO2.)
1 Connect the DC terminal of the AC adapter to the DC
input terminal of the DC coupler.
2 Make sure that the camera is turned off and open the
battery/card cover.
Pull the battery/card cover in the direction of 1 and flip the cover open
in the direction of 2.
3 Insert the DC coupler into the battery compartment,
making sure the (+) and (–) on the coupler match the (+)
and (–) on the battery compartment.
4 Open the DC coupler cable cover, pass the DC coupler
cable through the opening, and close the battery/card
cover.
Slide the battery/card cover in the opposite direction of 1. Slide the
battery/card cover all the way in to make sure it is securely closed.
5 Connect the AC plug cord to the AC adapter.
6 Plug the AC plug cord into the power outlet.
Using the AC Adapter with a Household Power Supply
4
AC adapter
AC plug cord
DC terminal
2
3
1
5
6
DC input terminal
DC coupler
DC coupler cable cover
DC coupler cable
To Next Page
