15
Powering the Camera
Use the rechargeable lithium-ion battery D-LI92 that is provided with the camera.
1
Open the battery/card cover.
Press the battery/card cover lock lever in the direction shown 1, slide the cover
towards 2 and open it towards 3.
2
Using the side of the battery to press the battery lock lever in
the direction of 4, insert the battery with the PENTAX logo
pointing toward the lens.
Push the battery in until it is locked in place.
3
Close the battery/card cover.
Push down and slide the battery/card cover with steady but gentle force in the
opposite direction indicated by 2.
The battery/card cover may be difficult to close because the waterproof packing
is very thick to prevent water from entering the camera.
To close the battery/card cover, push down on it toward the camera with your
thumb where it says [PUSH]. Then slide it until the battery/card cover lock lever
slides into place covering the yellow mark on the lock lever.
Installing the Battery
If the battery is incorrectly oriented, malfunction may result.
Battery/card cover
lock lever
Battery lock lever
Battery/card
cover
Battery
e_kb615_StartGuide.fm Page 15 Tuesday, October 17, 2023 9:26 AM
