Operator’s manual Pentruder RS2 wall saw and Pentpak 3 HFi power pack – Original instructions Page 35
5.2.2 Indications on RRC display
Contact your Pentruder authorized service workshop for information.
5.2.3 Error codes on RRC display
Error code Description
Method to reset
Unplug from
mains
supply
Remote
control
Automatic
reset
E1001
Pentpak ambient temperature too high
x
E1002
Pentpak cooling system, temperature too high
x
E1201, E1301
Emergency stop or Green button on Pentpak faulty
x
E1003
Main motor shut off due to slip clutch slipping
MS
E1004, E1604, E1605
Main motor temperature sensor fault
x
E1008, E1608, E1609
Arm feed motor temperature sensor fault
x
E1006, E1606, E1607
Travel motor temperature sensor fault
x
E1200, E1202-E1217
E1300, E1302-E1317
Internal fault, Pentpak control card
x
E1400
Internal fault, Pentpak control card, radio module
x
E1600
Saw arm position sensor fault
x
E1602
Slip clutch sensor fault
x
E1607
Main motor overheated
x
E1009
Arm feed motor overheated
x
E1007
Travel motor overheated
x
E1699
No communication with saw unit, RS2
x
E1800
Remote control switch/button/joystick sensor fault
x
E1801
Remote control battery charging fault
x
E2100, E2101
Hardware error, Pentpak, drive board, arm feed
x
E2200, E2201
Hardware error, Pentpak, drive board, travel
x
E2400, E2401
Hardware error, Pentpak, drive board, main motor
x
E2102, E2202, E2402
Machine cable failure, open circuit
x
E2103, E2203, E2403
Machine cable failure, leakage or faulty connection
x
E2109
Overcurrent detected, arm feed
Joystick
E2209
Overcurrent detected, travel
Joystick
E2409
Overcurrent detected, main motor
MS
E2111, E2211, E2411
Internal fault, Pentpak, drive board
x
E2113, E2213, E2413
Over voltage, mains supply to Pentpak
MS
E2114, E2214, E2414
Under voltage, mains supply to Pentpak
MS
E2115, E2215, E2415
Internal fault, Pentpak drive board
x
E2808-E2813
Pentpak rectifier fault
x
E2850
Under voltage, mains supply to Pentpak
MS
E2851
Over voltage, mains supply to Pentpak
MS
E2853
Line phase missing, mains supply to Pentpak
x
There are more Error codes which can occur. Contact your Pentruder authorized service workshop for information.
