Testing
Once the PMG/PCG and Display are paired, a full test is recommended. Follow the steps below to confirm function.
First, login to the device. If you do not have a Driver ID/Password, contact your system administrator for a test ID.
Once logged in, verify the following:
 Go to SystemOBC DiagnosticDiagnostic Basic and verify:
o GPS=3D Indicates the GPS is currently reading. This may not show if the vehicle is indoors.
o Cell Strength is >2 Indicates relative cell signal strength on a scale of 0-7.
 Go to SystemOBC DiagnosticDiagnostic Device and verify:
o Ignition reads ON when the vehicle key is on and OFF when the key is off and OFF in accessory.
 With the key ON, go to SystemOBC DiagnosticDiagnostic PerformX and verify:
o RPM matches engine
o Odometer Type: ECM and Odo: matches dash
o FUEL TYPE = ECM and FUEL: >0 gallons
 Confirm the Display Power button LED is green, indicating charging
o Disconnect the PD5 from the cable and verify the LED turns to Blue and the display remains powered up
NOTE: A fully charged battery will supply power for roughly 15 minutes, though a new unit may not have
a full charge
 Any accessories (Satellite, OBDii, GPIO, PTO) activated and confirmed. See accessory guide for details.
