BTC12N-*
Installation
Figure 3.2 Vertical mounting
≥ 50 mm
≥ 50 mm
≥ 50 mm
≥ 100
mm
≥ 50 mm
Danger!
Ambient conditions
Do not operate the device outside the specified ambient temperature.
Warning!
Hot surface
The surface of the device may become hot during operation.
