BTC12N-*
Installation
2020-05
15
DIN Rail Mounting
Tools and installation materials required:
Screwdriver
4 anchors, 4 screws (included in scope of delivery)
1. Attach the DIN rail adapter to the back of the BTC12. Use the thread on the bottom of the
BTC12 to secure the adapter. Tighten the supplied screws to a tightening torque of 0.4 Nm.
Figure 3.3
