WCS* Read Head Position Encoding System
SSI Interface (LS3xx*)
2020-01
33
Output of a warning if the lenses are contaminated
Adjusting the Display
You can rotate the character position on the display 180° using the S1D DIP switch. This allows
you to read the displayed values easily regardless of the installation position of the read head.
Read head type
Configuration switch "S1"
Code1 2 3 4
WCS2B-LS31*
WCS3B-LS31*
X OFF X OFF ON
WCS2B-LS31*
WCS3B-LS31*
X OFF X ON OFF
WCS3B
Display
position
Configuration switch "S1D"
Comment1 2
0° OFF OFF The displayed value can be read on a code rail
mounted upright.
180° ON ON The displayed value can be read on a code rail
mounted suspended.
