WCS* Read Head Position Encoding System
Model Overview for WCS Read Heads
10 Model Overview for WCS Read Heads
Type 2B WCS2B read head (smaller enclosure, 1200 pos./m
with a maximum of 327 m)
3B WCS3B read head (1250 pos./m with a maximum of
314.573 m)
3R WCS3R read head (833 pos./m with a maximum of 39.3
m)
3T WCS3T read head (416 pos./m with a maximum of 78.6
m)
Hardware 1 Read head with RS-485 interface, no RS-485 termina-
tor
2 Read head with RS-485 interface, with RS-485 termina-
tor
3 Read head with SSI interface
4 Read head with CANopen interface
5 Read head with EtherNet/IP interface
6 Read head with PROFINET Interface
Baud rate Read head with RS-485 interface
1 187.50 kBaud
2 62.50 kBaud
3 31.25 kBaud
4 19.20 kBaud
5 9.60 kBaud
6 38.40 kBaud
Read head with SSI interface
1 100 kHz – 1000 kHz
Read head with CANopen interface
1 125 kBaud, 250 kBaud, 500 kBaud, 1 MBaud
Read head with EtherNet/IP interface
1 100 Mbit/s
Read head with PROFINET Interface
1 100 Mbit/s
WCS.-LS . . . . .
-
Lesekopfadresse
Option(en)
Datenprotokoll
Baudrate
Hardware
Typ
