Pepperl+Fuchs WCS Series User Manual

WCS* Read Head Position Encoding System
Model Overview for WCS Read Heads
2020-01
71
Data log Read head with RS-485 interface
1
Data log 1, data log 2
1
1. Data log depends on read head request byte
6 Data log 3 with even parity (9 bit/byte)
7 Data log 3 without parity (8 bit/byte)
Read head with SSI interface
0 Data output in binary code
1 Data output in Gray code
Read head with a CANopen, EtherNet/IP, and PROFINET interface
0 Data output in binary code
Option D Read head with optional integrated display
E Read head with "Extended" option
H Read head with optional heating
S Read head with optional velocity output
OM Read head with "Outdoor" option (IP69K) and central
cable outlet
OL Read head with "Outdoor" option (IP69K) and left-hand-
side cable outlet
OR Read head with "Outdoor" option (IP69K), and right-
hand-side cable outlet
Read head
address
Read head with RS-485 interface
0 Read head address 0
1 Read head address 1
2 Read head address 2
3 Read head address 3
- Read head address 0
