Pepwave Surf Series User Manual

PePWave Surf/Mesh Connector/CarFi Series User Manual
Page
7
3.3.2 Surf DX Series LED Description
3.3.3 Mesh Connector Indoor / CarFi Series LED Description
LED Color Status Description
Green On Power is on
Power
Off Power is off
Green Solid Received signal is Excellent, Very Good and Good
Status
Off Booting up / Upgrading firmware
Green On Ethernet is connected
LAN
Off Ethernet is not connected
Green N/A Associated with an access point
Wi-Fi
Off Not associated with any access point
LED Color Status Description
Green On Power is on
PWR
Off Power is off
Green On Ethernet is connected
LAN
Off Ethernet is not connected
Green On
Associated with an access point. The
number of LED lights from “MIN” to
“MAX” indicates the received signal
strength level.
Wi-Fi
Off Not associated with any access point
