Parts List for Model LE1807CA
6
Important: Use only Grand Hall certified replacement parts. The use of any part that is not a factory
authorized part can be dangerous and will also void your product warranty. Keep this Operator's Manual
for convenient referral and for part replacement.
To Order Grand Hall Certified Replacement Parts, Call 1-877-550-8041
To obtain the correct replacement parts for your electric grill, please refer to the part numbers in this parts
list. The following information is required to ensure you receive the correct parts:
1. Model and Serial Number (see UL label on grill)
2. Part Number
3. Part Description
4. Quantity of parts needed
Parts List for Model LE1808CA
KEY PART DESCRIPTION PART # QTY
1 Lid PD01010015 1
2 Lid Trim Plate PD01020012 1
3 Lid Handle PD02010015 1
4 Name Plate P00414041C 1
5 Lid Latch, Upper PD03010011 2
6 Lid Latch, Lower PD03020011 2
7 Bowl, Outer PD04010015 1
8 Bowl, Inner PD04020012 1
9 Burner, Electric PD05010010 1
10 Cooking Grid PD07010013 1
11 Thermostat Bracket PD08010025 1
12 Thermostat Protector PD08010042 1
13 Burner Bracket PD16010025 1
14 Control Panel Heat Shield PD08010015 1
15 Control Panel Assembly PD09010015 1
16 Control Knob PD13010050 1
17 Leg, Foldable PD17030015 4
18 Leg Grip PD17040015 4
19 Grease Draining Tray PD14010012 1
20 Grease Receptacle PD14020012 1
21 Grease Tray Bracket PD16040015 2
22 Bowl Bracket PD16010042 2
23 Side Shelf Bracket, LF/RR PD16030032 2
24 Side Shelf Bracket, RF/LR PD16030042 2
25 Side Shelf, Left PD19010022 1
26 Side Shelf, Right PD19020022 1
27 Cart Leg, Upper PD17010032 4
2
Cart Bottom Shelf PD20010012 1
29 Cart Leg, Lower Left PD17020012 2
30 Cart Leg, Lower Right PD17020032 2
31 End Cap, Leg PD21010010 2
32 Wheel Axle PD18010015 1
33 Wheel P05101001A 2
34 Wheel Hub Cap P05116001B 2
35 Cart Leg Protective Pad, Lower Left PD17020056 2
Hardware Pack P06027002A 1
Operator's Manual P80173002H 1
Note: This grill can be assembled in approximately 30 minutes.
