Performance Tool M562DB User Manual

6
1 – Housing 1
2 – Anvil Bushing 1
3 M562K-01 Anvil Collet 1
4 M562K-01 O-Ring 1
5 M562K-01 Anvil 1
6 – Hammer Pin 1
7 M562K-01 Hammer Dog 1
8 M562K-01 Drive Cam 1
9 – Hammer Cage 1
10 – Screw 1
11 – Trigger Pin 2
12 – Trigger Pin 1
13 M562K-01 Front Bearing 1
14 – Protective Rubber 1
15 M562K-01 Front Plate 1
16 – Rotor 1
17 M562K-01 Rotor Blade 6
18 – Cylinder 1
19 – Cylinder pin 1
20 M562K-01 Rear Cover 1
21 M562K-01 Rear Bearing 1
22 – Seal Gasket 1
23 – Seal Cover 2
24 – Inlet Seat 1
25 – Air Regulator 1
26 M562K-01 O-Ring 6
27 M562K-01 O-Ring 2
28 – Spring 2
29 – Switch Pin 2
30 – Switch Spring 2
31 – Valve Seat 2
32 M562K-01 O-Ring 1
33 M562-01 O-Ring 1
34 – Screw 4
35 – Gasket 1
36 – Anvil Collet 1
37 – Spring 1
38 – Steel Ball 1
39 – Retainer Plate 1
40 – Screw 2
41 – Oil seal 1
# Part # Description Quantity
REPLACEMENT PARTS LIST

Performance Tool M562DB Specifications

General

Brand	Performance Tool
Model	M562DB
Category	Impact Driver
Language	English
