Performance Tool M708 User Manual

4
REPLACEMENT PARTS LIST
REPLACEMENT PARTS LIST
1. Gun body 1
2. Nozzle Cap 1
3. Washer 1
4. Air Nozzle 1
5. Snap Ring 1
6. Fluid Nozzle 1
7. Brass Ring 1
8. Nylon Gasket 1
9. Packing Bushing 1
10. Washer 2
11. Needle 1
12. Spring 1
13. Lock Nut 1
14. Fluid Volume Control Knob 1
15. Paint Cup Bushing 1
16. Trigger 1
17. Trigger Pivot Pin 1
18. Needle Actuator Pin 1
19. E-Clip 3
20. Spray Regulator Nut 1
# Description Qty. # Description Qty.

Performance Tool M708 Specifications

General

Brand	Performance Tool
Model	M708
Category	Paint Sprayer
Language	English
